5 Operation
34 Operating Manual ARC 350 900-351_IFU_V2.0.0_20221-S0-20150520-EN
3. Confirm your selection by pressing the "OK" button.
- or -
To return to the main screen without changing the selection, tap any button
outside the selection menu.
5.4.4. Assigning the foot pedal
Handles and instruments with manual switches can be activated without
a configuration setting.
A single-pedal foot switch and/or double-pedal foot switch, each with a changeover
switch, can be connected,
The changeover switch enables switching between pedal levels.
1. Select the foot switch menu using the selection of the respective socket
A menu appears for selecting the program, foot switch assignment as well as
modes for cutting or coagulation.
2. Enter the selection menu of the footswitch using the “Pedal” button on.
Figure 5-8: Foot switch selection
3. Select the required foot switch by pressing the corresponding button.
For example, you could select the active pedal level for cutting, and
coagulation for the top, left-hand socket.
- or-
Deactivate the footswitch using the “Off“ button.
4. Confirm the selection by pressing the "OK" button.
- or-
To return to the main screen without changing the selection, tap any button
outside the selection menu.
