5 Operation
62 Operating Manual ARC 350 900-351_IFU_V2.0.0_20221-S0-20150520-EN
Saving device settings
With the function "Backup device" device settings can be saved on the BOWA
USB Stick (REF 900-402). This includes all stored programs and system settings.
Transferring device settings
Use "Restore device" to transfer saved device settings from a BOWA USB Stick
(REF 900-402) to the ARC 350 unit.
EASY resistance monitor
With "EASY monitor" the resistance at the neutral electrode is displayed.
Configuring the startup screen
In ARC 350 is a possibility to create a personalized startup screen. This appears
after switching on the device for a selectable duration.
1. Create a folder with the name "arc_logo" on the USB flash drive
(REF 900-402).
2. Open the Windows program " Notepad.exe " and enter a number between 5
and 60 for the displayed duration in seconds.
3. Save this file on the USB flash drive in the folder "arc_logo" under the name
"KH_Logo.conf". Make sure that the file is stored as type "All Files ( *. *)" and
encoding "UTF -8".
4. Create a startup screen with a resolution of 240 x 320 pixels and save it under
the name "KH_Logo_arc350.png" in the folder "arc_logo".
5. Plug the USB flash drive with the files created in the USB port of the ARC 400
and turn the unit on using the main switch.
6. Wait until the ARC 350 is fully booted and the user interface appears.
7. Turn on the ARC 350 and remove your USB flash drive.
Now your generated startup screen is permanently stored in the device and
appears after every switching-on for the specified duration.
In the service menu, the stored startup screen can be deleted using
"Remove logo".
Resetting to factory settings
The "Reset to default" function allows you to reset all settings and programs to
factory settings.
