CLP Rollform Pipe Marker
To use a CLP Rollform Pipe Marker label type:
1. From the Home Page, touch More Label Types button , then touch CLP Pipe
Markers.
2. On the CLP Pipe Marker screen, touch Create New File .
3. On the Pipe Marker Style screen, touch Rollform .
4. In the Dimensions dialog, touch the Pipe diameter: data field and enter the diameter of the
pipe to which the label will be afixed.
5. In the Tape width: field, touch the desired Tape Width, then touch Next .
In the Pipe contents dialog box, choose the type of material that flows through the pipe.
6. Touch the up/down arrows to view more options in the list.
7. When found, touch the desired contents option to select it, then touch Next .
The material selected determines the pipe marker colors based on the selected color norm in
the Pipe Marker setup menu. (See page 143 for Pipe Marker setup.)
8. On the Legend screen, in the Chemical name: field, enter the name of the substance that
flows through the pipe. (#8 in instructions)
OR, in the displayed list:
Touch the name of the substance.
To Next Page
