Labels
Rev A 101 BBP
®
35/37 User’s Manual
3. In the Label Size & Orientation dialog box, touch Fixed Length option box.
4. In the Fixed Length data field, enter the desired label length.
Note: For single-color printing, the minimum supported length (after cutting) is 2
in. (51 mm). The maximum supported length is 16 ft (5 m). For multi-paneled
ribbon, the label length is limited to 15 in. (381 mm). If doing multi-colored
printing using mono-colored ribbons (i.e., swapping out the different colored
ribbons), the maximum length is 48 in. (1219 mm). If printing with paneled multi-
colored ribbons installed, you are limited by the length of the panel.
5. Touch OK .
The Status Bar and the rulers indicates the new label length. To return to Auto-Sizing:
1. Touch Menu .
2. Under Label, touch Size & Orientation .
3. In the Label Size & Orientation dialog box, touch Autosize to Fit Data option box.
4. Touch OK .
Orientation
You can print labels in portrait or landscape orientation. Portrait orients the label data elements
lengthwise from top to bottom. Landscape rotates the label data, printing lengthwise from left
to right. To set the label orientation:
1. Touch Menu .
2. Under Label, touch Size & Orientation .
3. Under Label orientation, touch Portrait or Landscape to achieve the desired
print orientation of your label.
