Formatting a Label
Rev A 71 BBP
®
35/37 User’s Manual
Graphic Object Elements
Use the graphic object to place pictures, shapes, or signs on your label.
To add a graphic object element:
1. Touch anywhere in the Editor.
OR, if you are already in a label:
Touch Add Object .
2. In the Add Object control panel, touch Graphic .
3. In the Select Graphics dialog box, under Category, touch the category containing the
graphic you want to add.
4. In the displayed list of graphics, touch the desired graphic.
The graphic is added to the label.
Importing Graphics
You can also import your own graphics and use them just as you would use the graphics
included in the BBP
®
35/37 printer. You import graphics through the use of a USB flash drive.
The imported graphics must be in the supported file format of Windows metafile (*.wmf) or a
monochrome bitmap (*.bmp). Windows metafile (*.wmf) formats are vector images that
maintain their clarity and crispness when they are resized. Bitmap files (*.bmp) are composed
of pixels which may appear fuzzy and become distorted when they are resized. You can also
import portable network graphics (*.png) and Joint Photographic [Experts] Group graphics
(*.jpg). Be sure to choose the correct format for the graphic you are using.
The maximum size for graphics that can be imported is 1 megapixel (the height x width of the
graphic = 1,000,000 pixels). Larger graphic files cannot be imported. If you get an “out-of-
memory” error when importing an image, it means the image is too large. Try resizing the
graphic on your PC to a smaller size, then import the graphic.
Note: Any paint program on your PC will indicate the image size when you open
the image file. Use that paint program to resize the image to fit the memory
requirements on the BBP
®
35/37 printer.
You can also import colored graphics, however the color of an imported graphic cannot be
changed. The color picker feature is disabled when working with an imported colored graphic.
