Braun Infusomat Space Service Manual

Unit Diagnosis / Calibration
2
Infusomat® Space 6.0 2 - 3EN
Error Codes of the Function Processor
Error Code Definition Possible Cause Fault Clearance
1 2001 ... 2013 Internal Error
2 2014 ... 2016 Loudspeaker Loudspeaker connector Check the loudspeaker connector.
Loudspeaker Check the loudspeaker.
3 2017 KUP does not work Software defective or obsolete Update software, change ISP processor
PCB if
necessary
4 2018 FUP-KUP OS Cycle Timeout Software defective or obsolete
5 2019 FUP Flash Memory Error Software defective or obsolete
6 2020 FUP different version KuP to FuP Software defective or obsolete
7 2021 FUP UPSTREAM TOO HIGH Upstream pressure sensor defective Replace upstream pressure sensor
8 2022 FUP UPSTREAM TOO LOW Upstream pressure sensor defective
9 2023 FUP DOWNSTREAM TOO HIGH Downstream pressure sensor de-
fective
Replace downstream pressure sensor
10 2024 FUP DOWNSTREAM TOO LOW Downstream pressure sensor de-
fective
11 2025 FUP EA key closed too long Keyboard defective Exchange operating unit
12 2026 Internal Error
13 2027 ... 2033 FUP Airsensor
FUP Temperature Sensors
Air sensor defective Check ribbon cable of air sensor.
Replace air sensor
14 2034 FUP CAN packet scheduler list
failu
re
CAN communication error Restart device
15 2035 Light barrier or motor defective/
turn backwards
Light barrier defective Exchange processor PCB
16 2036 FUP Language Flash Memory Er-
ror
Language file faulty Update software
17 2037 FUP Language Version Error Language file faulty Update software
18 2038 Internal Error
19 2039 FuP collective CAN Alarm Two pumps with identical serial
num
ber in system
Check and correct serial numbers.
20 2040 ... 2041 Internal error
21 2042 ... 2051 FUP Syncdata KuP Error in synchronization with the
control p
rocessor
22 2052 ... 2053 Internal error
23 2060 ... 2085 TCI Error Error in relation to TCI therapy to-
gether with special settings
Restart the device, change settings
slightly if necessary
. If the error persists:
Please load the history file via HiBaSeD
and inform B. Braun
24 2088 ... 2090 Internal error
Table 2 - 2 Error Codes of the Function Processor
