Braun Infusomat Space Service Manual

Unit Diagnosis / Calibration
2
2 - 4 Infusomat® Space 6.0 EN
Error Codes of the Control Microprocessor
*
* Note: If alarm 2111 occurs during infusion, the device history logs may not be re-
trievable.
Error Code Definition Possible Cause Fault Clearance
1 2100 Timebase too fast Quartz of the processor PCB Exchange processor PCB
2 2101 Timebase too slow Quartz of the processor PCB Exchange processor PCB
3 2102 Timebase failure Quartz of the processor PCB Exchange processor PCB
4 2103 Keyboard High Keyboard defective Exchange operating unit
5 2104 ON/OFF key pressed too long Keyboard defective Exchange operating unit
6 2105 No keydecode Keyboard defective Exchange operating unit
7 2106 ROM Romtest defective Software Update unit software
8 2107 ROM program defective
9 2108 FuP has not changed active reset value
10 2109 MPU_Test failed
11 2110 RAM_Test failed
12 2111* KUP active reset Pump was not switched off cor-
rectly
Restart device
13 2112 2114 Internal Error
14 2115 Drive too fast Motor drive
Detection of direction of rotation
Exchange processor PCB
15 2116 Drive too slow
16 2117 ... 2118 Internal Error
17 2119 LCD backlight on defective LC display defective Exchange operating unit
18 2120 LCD backlight off defective
19 2121 Red LED on defective
20 2122 Red LED off defective
21 2123 Key pressed too long (without ON/OFF
key)
Keyboard defective Exchange operating unit
22 2124 ... 2127 Internal Error
23 2128 Drive motion incorrectly forward Motor drive
Detection of direction of rotation
Replace processor PCB
24 2129 Drive motion incorrectly backward
25 2130 ... 2159 Internal Error
26 2160 ... 2162 PCA Error Error in relation to PCA therapy
to
gether with special settings
Restart the device, change settings
slightly if necessary. If the error per-
sists: Please load the history file via
HiBaS
eD and inform B. Braun
27 2170 ... 2173 DLOCK Error Error in relation to Datalock to-
gether with special settings
Restart the device, change settings
slightly if necessary
. If the error per-
sists: Please load the history file via
HiBaS
eD and inform B. Braun
Table 2 - 3 Error Codes of the Control Microprocessor (Part 1 of 3)

Braun Infusomat Space Specifications

General

Type	Infusion Pump
Power Supply	AC/DC adapter, rechargeable battery
Display	Color graphic display
Alarms	Audible and visual alarms
Flow Rate Accuracy	±5%
Occlusion Pressure	Adjustable
VTBI Range	0.1 – 9999 ml
KVO Rate	0.1 – 5 ml/h (adjustable)
Battery	Lithium-ion
Operating Modes	Continuous
Certifications	CE, ISO 13485, IEC 60601-1
