Braun Infusomat Space Service Manual

Unit Diagnosis / Calibration
2
Infusomat® Space 6.0 2 - 5EN
28 2180 ... 2184 DRUG Error
DIFF Error
Error in relation to dose calcula-
tion together with special set-
tings
Restart the device, change settings
s
lightly if necessary. If the error per-
sists: Please load the history file via
HiBaSeD and inform B
. Braun
29 2199 ... 2200 Internal Error
30 2201 different version FuP to KuP Software Update unit software
31 2202 Stepper motor PH1A not 0 Stepper motor defective Replace pump drive motor or proces-
sor PCB
32 2203 Stepper motor not low current
33 2204 Stepper motor K_SM_CLK
34 2205 Stepper motor PH1A not 1
35 2206 Stepper motor not zero current
36 2207 Stepper motor not middle current
37 2208 Stepper motor not high current
38 2209 Stepper motor PH1A, PH1B, PH2A,
PH2B
not 0
39 2210 K_PKM_UB not off Lock bolt drive defective Replace lock bolt drive or processor
PCB
40 2211 K_PKM_UB not on
41 2215 no V_MOT Processor PCB defective Replace processor PCB
42 2216 Overvoltage test failure
43 2217 no V_MOT
44 2218 Undervoltage test failure
45 2220 Door potentiometer defective Lock bolt drive (potentiometer)
d
efective
Replace lock bolt drive
46 2221 Locking bolt position failure Software defective or obsolete Perform calibration.
Update software, change ISP proces-
sor PCB if necessary
47 2222 Temperature sensor difference Air sensor defective Replace air sensor
48 2223 Air sensor defective Disposable articles table for
S
pace Line Neutrapur incompat-
ible with existing air sensor
Compare air sensor version with dis-
posable article table and import new
dispo
sable article table, if necessary.
(see „Rework when Replacing the Air
Inline Sensor“ ➨ pg. 3 - 52)
Air sensor defective Replace air sensor
49 2224 Rate compensation difference Rate compensation error Update unit software
50 2225 Rate compensation max value
51 2226 Rate compensation min value
52 2227 Received air data defective Air sensor defective Replace air sensor
53 2228
Temperature sensor switch defective
Error Code Definition Possible Cause Fault Clearance
Table 2 - 3 Error Codes of the Control Microprocessor (Part 2 of 3)

Braun Infusomat Space Specifications

General

Type	Infusion Pump
Power Supply	AC/DC adapter, rechargeable battery
Display	Color graphic display
Alarms	Audible and visual alarms
Flow Rate Accuracy	±5%
Occlusion Pressure	Adjustable
VTBI Range	0.1 – 9999 ml
KVO Rate	0.1 – 5 ml/h (adjustable)
Battery	Lithium-ion
Operating Modes	Continuous
Certifications	CE, ISO 13485, IEC 60601-1
