Brooks GF Series - Dimensional Drawings

D-5
GF Series
Installation and Operation Manual
X-TMF-GF Series-MFC-eng
Part Number: 541B137AAG
March, 2010
Section D Misc. Drawings
D-2 Dimensional Drawings
The following drawings represent the available configurations for the Brooks Models GF100, GF120 and GF125.
Figure D-8 DeviceNet 1-1/8" C-Seal 92mm Downported
Figure D-9 Digital/Analog DB9, RS-485 1-1/8" C-Seal 92mm Downported
