HMI Top Menu
C1 MODE
C2 MODE
MONITORED TEMP XXX.X
USER MONITORED XXX.X
TOP MENU
CKT1 MODE>
CKT2 MODE>
COMPRESSOR ON/OFF>
SYSTEM STATUS>
FAULT STATE>
CONFIGURATION>
SERVICE MENU>
CKT 1 MODE
COOL
STANDBY*
DEFROST
SYSTEM STATUS
SHOW ALL>
CRYO COOLER>
CKT1 STATUS>
CKT2 STATUS>
STACK STATE SCREEN>
FAULT STATE
NO FAULT
CKT 2 MODE
COOL
STANDBY*
DEFROST
COMPRESSOR ON/OFF
COMPRESSOR ON*
COMPRESSOR OFF
CONFIGURATION
CONTROL CONFIG>
MONITOR CONFIG>
SET COMM PARAMS>
SET PRESSURE UNITS>
DATE XX-XX-XXXX
TIME XX:XX:XX
SERVICE MENU
S/N XXXXXXXXX
M/N XXXXXXXXX
SW VER XX.XX.XX.XX
DSP VER XX.XX.XX.XX
CPRS HRS XX
LAST RCHG
AUTHORIZATION CODE
Go to
Configuration
Page 1 on page
5-9
Go to
Basic Service
on page 5-13
Go to
System Status
on page 5-8
