Brooks Polycold MaxCool Series - Specifications and Site Preparation

Polycold Cryochiller
Installation and Operation Manual
Brooks Automation
214072 Revision B
3-1
3 Specifications and Site Preparation
Physical Specifications
NOTE: All units have cold elements that may be decoupled from the refrigerant lines.
NOTE: Maximum angle of inclination for shipping or handling all units is forty-five degrees (45°).
When moving units using pallet jack or optional casters must be moved on level floors only.
NOTE: All specifications are for the standard product configuration. Specifications can vary for
customized configurations
NOTE: Sound measurements were made on each side of the unit at a distance of 1.0m (39 in) and
at a height of 1.6m (63 in). Measurements taken from each side of the unit did not vary sig-
nificantly. Measurements will vary with the acoustics of the environment.
Table 3-1: Physical Specifications
Parameter MaxCool 4000H MaxCool 2500L
Width - mm (inch) 813 (32) 813 (32)
Depth - mm (inch) 663 (26.1) 663 (26.1)
Height - mm (inch)
(without castors or lifting hooks)
1791 (70.5) 1791 (70.5)
Min. room volume, m
3
(ft
3
)
(per ASHRAE 15 and EN 378-1)
33.98 (1200) 39.64 (1400)
Weight kg (lb) 533 (1175) 544 (1200)
Shipping Weight kg (lb) 567 (1250) 578 (1275)
Cooling Water Connection 3/4 NPT Female 3/4 NPT Female
Max. operating sound level, dB(A) 78 78
Max. operating sound level with sound
attenuation option dB (A)
69 69
