Brooks Polycold MaxCool Series - Circ_Feed_Temp; Circ_Rtn_Temp

Polycold Cryochiller Host Commands
Installation and Operation Manual Circuit Sensor Readings Commands
Brooks Automation
214072 Revision B
7-39
CIRC_FEED_TEMP Circuit Feed Temperature
CIRC_RTN_TEMP Circuit Return Temperature
Interface RS-232, Ethernet
Purpose: Read the circuit feed temperature sensor value.TC13 / TC14
Parameter(s): [n],?
[n] is circuit number (1 or 2)
Return Value: [A][nnn.n]
Default Value: N/A
Security Level Get: 1 Set: N/A
Example: “CIRC_FEED_TEMP,1,?”
Interface RS-232, Ethernet
Purpose: Read the circuit return temperature sensor value. TC3 / TC5
Parameter(s): [n],?
[n] is circuit number (1 or 2)
Return Value: [A][nnn.n]
Default Value: N/A
Security Level Get: 1 Set: N/A
Example: “CIRC_RTN_TEMP,1,?”
Interface RS-232, Ethernet
