Brooks Polycold MaxCool Series - System Illustration

Introduction Polycold Cryochiller
System Illustration Installation and Operation Manual
Brooks Automation
1-2 214072 Revision B
System Illustration
Figure 1-1: Illustration of MaxCool Cryochiller
Circuit
HMI
Display
and
Keypad
EMO Switch
(optional)
Communications
Panel
Power In
Water In / Out
Circuit 1
Refrigerant
Lines
Feed (left)
Return (right)
(optional)
Circuit 2
Refrigerant
Lines
Feed (left)
Return (right)
Lift Rings (optional)
Breakers
