3-19
Confidential
12
The entire lower cover
(3_026)
Ink supply tubes
ASF encoder sensor
harness
Purge cam switch harness
Speaker harness
Power supply harness
Paper feed motor
harness
ASF motor harness
Carriage motor
harness
PF/registration sensor
harness
Pressure roller release
sensor harness
Ink cartridge cover sensor harness
Disc guide sensor harness
