Brother DCP-J752DW

3-47
Confidential
Assembling Note
• Assemble new CIS flat cable following the steps below.
1) Fold CIS flat cable and affix the double-sided tape as shown below.
84
12.5
28
217
51.9
110.7
248
105.8
111.5 38.5
87.5
56
86.8
22
1066.4
385.5
248115.5
45°45°
45° 45°
2.5
12.5
56 28 38.5
12
2.5
8
105.8 246.6217
45°
45°
45°
28.5°
28.5°
222.7
84
12.533
110.7
(3_060)
Double-sided tape position
Mountain fold
Valley fold
Folding Instruction
CIS unit side
UL notation
printing surface
Double-sided tape (affixed on the
reverse side)
Main unit side
Double-sided tape
UL notation
printing surface
Main unit side
UL notation printing surface
(Unit: mm)
CIS unit side
