Brother DCP-L2500D Service Manual

2-87
Confidential
4.11.3 Document jam
 Paper jam in the ADF cover
 Paper jam in the ADF
<User Check>
- Check that the paper used for the document is not thinner than 64 g/m
2
.
- Check that the paper used for the document is not shorter than 147.3 mm.
- Check that the number of paper set has not exceeded the upper limit in the paper tray.
- Check that the ADF cover is closed correctly.
Step Cause Remedy
1
Foreign object inside the area
around ADF cover
Remove foreign objects inside the area
around the ADF cover.
2
First side document scanning
position actuator coming off
Reattach the first side document scanning
position actuator.
3
ADF cover actuator caught in some
sections of the machine
Reattach the ADF cover actuator.
4
Document pinch roller coming off Reattach the document pinch roller.
5
Second side white bar coming off Reattach the second side white bar.
6
Connection failure of first side
document scanning position sensor
PCB harness
Check the connection of the first side
document scanning position sensor PCB
harness, and reconnect it if necessary.
7
Abrasion of document feed roller Replace the document feed roller ASSY 1.
8
First side document scanning
position sensor failure
Replace the first side document scanning
position sensor PCB ASSY.
9
ADF cover sensor failure Replace the ADF cover/document detection
sensor PCB ASSY.
10
Main PCB failure Replace the main PCB ASSY.
<User Check>
- Check that the paper used for the document is not thinner than 64 g/m
2
.
- Check that the paper used for the document is not longer than 900 mm (400 mm when
duplex scanning).
- Check that the document guide is adjusted to suit the document width.
Step Cause Remedy
1
Foreign object inside the ADF Remove foreign objects inside the ADF
2
Second side document scanning
position actuator coming off
Reattach the second side document
scanning position actuator.
3
First side white bar coming off Reattach the first side white bar.
4
Fed at an angle and jammed due to
abrasion of separation roller
Replace the separation roller ASSY.
5
Connection failure of second side
document scanning position sensor
PCB harness
Check the connection of the second side
document scanning position sensor PCB
harness, and reconnect it if necessary.
6
Second side document scanning
position sensor failure
Replace the second side document scanning
position sensor PCB ASSY.
7
Main PCB failure Replace the main PCB ASSY.

Brother DCP-L2500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	6.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 6, 9, 16, 25
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	26 cpm
Scan to	E-mail, File, Image, OCR
Scan drivers	ICA, SANE, TWAIN, WIA
Grayscale levels	256
Input color depth	30 bit
Maximum scan area	A4 (210 x 297) mm
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Faxing	No
Printing colors	Black
Maximum duty cycle	10000 pages per month
Recommended duty cycle	250 - 2000 pages per month
Number of print cartridges	1
Page description languages	GDI
Processor family	ARM9
Sound power level (standby)	33 dB
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	45 dB
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Display	LCD
Product color	Black, Grey
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Online services supported	Evernote
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Direct printing	-
Standard interfaces	USB 1.1, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1104 W
Power consumption (off)	0.08 W
Power consumption (standby)	60 W
Power consumption (PowerSave)	6.6 W
Power consumption (average operating)	480 W
Minimum storage drive space	500 MB
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
Package depth	567 mm
Package width	517 mm
Package height	414 mm
Package weight	12500 g
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	409 mm
Width	398.5 mm
Height	267 mm
