3-46

Confidential

9.12.8 Document Feed Roller ASSY 1

(1) Release the lock of the conductive bushing to remove the document feed roller ASSY 2.

Fig. 3-36

Document feed roller ASSY 2

Conductive bushing

Lock

Conductive bushing
