Brother DCP-L2500D Service Manual

2-23
Confidential
3.2.2 Touch panel models
Error Messages
Description
Error
codes
Refer
to:
Upper line Lower line
Access Denied Function Locked Failed in print limit ID
authentification on PC print or PC
print is forbidden.
--- 2-85
Function Locked. Job
Deleted. Press Stop
[X].
Failed in print limit ID
authentification on Secure print or
PC print is forbidden.
--- 2-85
Cartridge Error Put the Toner
Cartridge back in.
The new toner sensor could not
detect the new toner cartridge
correctly.
4F01 2-39
Cooling Down Wait for a while The side thermistor of the fuser
unit or the internal temperature
sensor detected a temperature
higher than the specified value.
6801 2-41
Cover is Open Close the ADF Cover. The ADF cover sensor detected
that the ADF cover was open.
A400 2-51
Close the Front Cover. The front cover sensor detected
that the front cover was open.
6001 2-40
Close the Back Cover
of the machine.
The eject sensor detected that the
fuser cover was open.
6004 2-40
Make sure there is no
paper jammed inside
the machine and close
the Back Cover, then
press [Retry].
The eject sensor was ON when the
power switch was turned ON.
7C00 2-46
Document Jam Open the ADF cover
and clear the scanner
jam, then press
Stop[x].
The first side document scanning
position sensor detected that the
document length was 90 cm or
longer while scanning the
document.
A200 2-50
The first side document scanning
position sensor has not detected
the top of the document even after
the document has been fed for the
specified distance.
A300 2-51
Drum ! Open the Front Cover
and slide the green tab
across the Drum Unit
several times.
Detected discharge that may be
attributable to dirty corona wire on
the drum unit.
6A00 2-43
Failed to Set Make sure the phone
line is connected. If
connection fails, call
phone service
company. Press
stop[x] if you do not
connect a phone line.
Completed auto-detect as line cord
remained connected to the
external terminal.
--- 2-94
Jam 2-sided Pull out the 2-sided
Tray and remove the
jammed paper.
The registration front sensor does
not detect paper pass within the
specified time after the first side
was printed in duplex printing
mode.
7700 2-46

Brother DCP-L2500D Specifications

General

Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Duplex printing mode	Auto
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	26 ppm
Duplex print speed (black, normal quality, A4/US Letter)	6.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 6, 9, 16, 25
Time to first copy (black, normal)	10 s
Copy speed (black, normal quality, A4)	26 cpm
Scan to	E-mail, File, Image, OCR
Scan drivers	ICA, SANE, TWAIN, WIA
Grayscale levels	256
Input color depth	30 bit
Maximum scan area	A4 (210 x 297) mm
Output color depth	24 bit
Maximum scan resolution	19200 x 19200 DPI
Optical scanning resolution	600 x 2400 DPI
Faxing	No
Printing colors	Black
Maximum duty cycle	10000 pages per month
Recommended duty cycle	250 - 2000 pages per month
Number of print cartridges	1
Page description languages	GDI
Processor family	ARM9
Sound power level (standby)	33 dB
Sound pressure level (printing)	49 dB
Sound pressure level (quiet mode)	45 dB
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Multi-Purpose tray input capacity	1 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Bond paper, Envelopes, Labels, Plain paper, Recycled paper, Thick paper, Thicker paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Executive
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Display	LCD
Product color	Black, Grey
Market positioning	Home & office
Display number of lines	2 lines
Display number of characters	16
Online services supported	Evernote
Mobile printing technologies	Apple AirPrint, Brother iPrint & Scan, Google Cloud Print
Direct printing	-
Standard interfaces	USB 1.1, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	1104 W
Power consumption (off)	0.08 W
Power consumption (standby)	60 W
Power consumption (PowerSave)	6.6 W
Power consumption (average operating)	480 W
Minimum storage drive space	500 MB
Mac operating systems supported	Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Windows operating systems supported	Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
Package depth	567 mm
Package width	517 mm
Package height	414 mm
Package weight	12500 g
Storage temperature (T-T)	0 - 40 °C
Operating temperature (T-T)	10 - 32 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Depth	409 mm
Width	398.5 mm
Height	267 mm
