Brother DCP-L2500D - Page 75

2-40
Confidential
 Error code 6001
The front cover sensor detected that the front cover was open.
 Error code 6004
The eject sensor detected that the fuser cover was open.
Cover is Open
Close the Front Cover.
<User Check>
• Close the front cover.
Step Cause Remedy
1
Front cover failure Replace the front cover.
2
Front cover sensor failure Replace the high-voltage power supply PCB
ASSY.
3
Main PCB failure Replace the main PCB ASSY.
Cover is Open
Close the Fuser Cover which can be found behind the Back Cover of the machine.
<User Check>
• Close the fuser cover.
Step Cause Remedy
1
Eject actuator coming off or
caught in sections of the
machine
Reattach the eject actuator.
2
Fuser cover attachment failure Reattach the fuser cover.
3
Connection failure of the eject
sensor PCB flat cable
Reconnect the eject sensor PCB flat cable.
4
Eject sensor PCB failure Replace the eject sensor PCB ASSY.
5
Main PCB failure Replace the main PCB ASSY.
