4.5 Troubleshooting for Network Problems

4.5.1 Cannot make a print through network connection

< User Check >

- Check the descriptions in the network User’s guide.

- Check the network connection.

- Perform network reset. (Refer to User's guide.)

- Check the LAN cable.

Step Cause Remedy

1 Connection failure of the

wireless LAN PCB harness

Reconnect the wireless LAN PCB harness.

2 Wireless LAN PCB failure Replace the wireless LAN PCB ASSY.

3 LAN terminal pin deformation

Main PCB failure

Replace the main PCB ASSY.
