4.6 Troubleshooting for Control Panel Problems

4.6.1 Nothing is displayed on the LCD

< User Check >

- Turn the power OFF/ON.

Step Cause Remedy

1 The version of the panel

firmware and the main

firmware do not match.

Install the latest panel firmware and main

firmware.

2 Connection failure of the key

PCB flat cable

Reconnect the key PCB flat cable.

3 Connection failure of the

panel PCB harness

Reconnect the panel PCB harness.

4 Connection failure of the LCD

flat cable

Reconnect the LCD flat cable.

5 Connection failure of the

low-voltage power supply

PCB harness

Reconnect the low-voltage power supply

PCB harness.

6 AC cord failure Replace the AC cord.

7 Panel PCB failure Replace the panel PCB unit.

8 LCD failure Replace the LCD.

9 Key PCB failure Replace the panel cover ASSY.

10 Low-voltage power supply

PCB failure

Replace the low-voltage power supply PCB

unit.

11 Main PCB failure Replace the main PCB ASSY.
