3-49
Confidential
9.9 Duplex Tray
(1) Remove the two Taptite cup B M3x12 screws and remove the Duplex tray from the Main
body.
Fig. 3-35
Taptite cup B M3x12
Main body
Taptite cup B M3x12
<Back side>
Duplex tray
