3-6

Confidential

Registration front/

rear sensor PCB holder

Taptite bind B M3x10 1 0.5±0.1 (5±1)

MP drive frame Taptite bind B M3x10 3 0.5±0.1 (5±1)

High-voltage power

supply PCB ASSY

Taptite pan B M3x10 1 0.5±0.1 (5±1)

T2 cover rear Taptite cup S M3x10 SR 2 0.8±0.1 (8±1)

T2 cover left Taptite cup S M3x6 SR 2 0.8±0.1 (8±1)

T2 cover right Taptite cup S M3x6 SR 2 0.8±0.1 (8±1)

T2 relay PCB ASSY Taptite cup S M3x6 SR 1 0.8±0.1 (8±1)

T2 beam F ASSY Taptite cup S M3x6 SR 5 0.8±0.1 (8±1)

T2 solenoid holder ASSY Taptite cup S M3x6 SR 1 0.8±0.1 (8±1)

T2 beam front Taptite cup S M3x6 SR 2 0.8±0.1 (8±1)

T2 beam rear Taptite cup S M3x6 SR 4 0.8±0.1 (8±1)

T2 frame L unit Taptite bind B M4x10 1 0.8±0.1 (8±1)

Location of screw Screw type Q' ty

Tightening torque

·m (kgf·cm)
