7-4

Confidential

(3) Remove the Shaft of the Back cover from the Bush on the right side of the Main body.

Fig. 7-3

(4) Remove the Back cover.

Fig. 7-4

Back cover

Bush

Main body

Shaft

Back cover

Main body

Default Chapter4
