HL-5240/5250DN/5270DN/5280DW SERVICE MANUAL
Confidential
5-75
(3) Pull out the Separation roller drive shaft to the direction of the arrow and remove the Edge
actuator and PE actuator.
Fig. 5-122
Edge actuator
PE actuator
Paper feed frame
Separation roller drive shaft
