5-75
Confidential
8.29 Wireless PCB (PCB T60H989 ASSY 04) (Wireless LAN model)
(1) Disconnect the connector from the Wireless PCB harness.
(2) Remove the Wireless PCB (PCB T60H989 ASSY 04) and Wireless PCB holder from the
Frame R.
Fig. 5-102
Frame RHook
Wireless PCB harness
Wireless PCB
(PCB T60H989 ASSY 04)
