2.2.2 Error indication at Service Calls
If LED indication does not operate when service calls occur, you can use a maintenance tool
to distinguish the type of error.
SIZE MISMATCH
Mismatch between specified paper size from the
driver and setting paper in the tray.
3-24
STORAGE FULL Memory full. 3-24
TOO MANY TRAYS Option tray is installed more than three. 3-24
REPLACE TONER Toner life end is detected. Developer count full. 3-25
TONER LOW Low on toner. 3-25
Error indication
(Printing of Printer Settings)
Error indication
(Printing of Maintenance)
Type of error
Refer
to:
ERROR S01 ERROR S01 ■ MAIN PCB FAILURE
3-25
ERROR S02 ERROR S02
ERROR S03 ERROR S03
ERROR S04 ERROR S04
ERROR S05 ERROR S05
ERROR S06 ERROR S06
ERROR S07 ERROR S07
ERROR S08 ERROR S08
ERROR S09 ERROR S09
ERROR S10 ERROR S10
ERROR S11 ERROR S11
ERROR S12 ERROR S12
ERROR S13 ERROR S13
ERROR E49 FUSER MALF 2 ■ FUSER UNITFAILURE
3-26ERROR E50 FUSER MALF
ERROR FUSER ERROR FUSER
ERROR E51 LASER BD MALF
■ LASER UNIT FAILURE
(Laser beam detection error)
3-26
ERROR E52 SCANNER MALF
■ LASER UNIT FAILURE
(Scanner motor failure)
3-26
ERROR E54 MOTOR MALF ■ MAIN MOTOR FAILURE 3-26
ERROR E55 HIGH VOL MALF
■ HIGH-VOLTAGE POWER
SUPPLY PCB FAILURE
3-27
ERROR E60 ERROR E60 ■ FAN FAILURE 3-27
ERROR H61 PROG ERROR ■ MAIN PCB FAILURE
3-25
ERROR H63 ERROR H63
ERROR H66 NV-W ERROR
ERROR H67 NV-R ERROR
ERROR H68 NV-B ERROR
