5-8
Confidential
6. HARNESS ROUTING
1 MP PE sensor ASSY
High-voltage PS PCB ASSY
Hook "B"
MP feed frame
MP feed frame
Hole
Hook "A"
Hook "A"
Printer top side
(Printer body upside down)
MP PE sensor ASSY
