5-3
Confidential
1.2 List of Maintenance Mode Functions
1.2.1 List of maintenance mode functions for LCD models
The maintenance mode functions shaded in the table can be used by end users.
Function
code
Function Refer to:
01 Initialize EEPROM parameters 1.3.1 (5-6)
09 Print test pattern 1.3.2 (5-7)
10 Set worker switches (WSW) 1.3.3 [1] (5-8)
11 Print worker switch (WSW) setting data 1.3.3 [2] (5-9)
12 Check LCD operation 1.3.4 (5-10)
13 Check control panel button operation 1.3.5 (5-11)
25 Display software version 1.3.6 (5-12)
28 Set One Push Demo function 1.3.7 (5-13)
32 Check sensor operation 1.3.8 (5-14)
33 Display LAN connection status 1.3.9 (5-16)
40 Print Dump List 1.3.10 (5-17)
45
Change USB No. return value / Adjust left-end print start
position on second side when duplex printing / Change
ON/OFF setting for Deep Sleep function
1.3.11 (5-18)
67 Continuous print test 1.3.12 (5-20)
69 Print frame pattern (single-side printing) 1.3.13 (5-22)
70 Print frame pattern (duplex printing) 1.3.14 (5-24)
71 Print solid pattern 1.3.15 (5-26)
74 Setting by country 1.3.16 (5-27)
77 Print maintenance information 1.3.17 (5-29)
78 Check fan operation 1.3.18 (5-31)
80 Display machine log information 1.3.19 (5-32)
82 Display machine error code 1.3.20 (5-34)
91 Initialize EEPROM parameters 1.3.1 (5-6)
99 Quit maintenance mode 1.3.21 (5-34)
