Brother HL-5450DN Service Manual

2-10
Confidential
3. ERROR INDICATIONS
This machine includes a self-diagnosis function. If the machine does not work normally it
judges that an error has occurred, and indicates the corresponding error message on the
LCD, which in turn helps the service men to quickly find out the problem.
3.1 Error Codes
The errors with a mesh background in the table below do not occur in the normal operation.
They might occur due to noise around the installation site, change of the power supply
voltage, and failures in the software.
Error
codes
Problem
Refer
to:
Error
codes
Problem
Refer
to:
0B00 An unidentified error occurred. 2-28 2900 An unidentified error occurred. 2-30
0C01
0C02
0C03
0C04
Log registration failed. 2-28 2A00 An unidentified error occurred. 2-30
0D00
Data cannot be saved because
storage data area in the memory
is full.
2-28
2B00 An unidentified error occurred. 2-30
0E00 An unidentified error occurred. 2-29 2C00 An unidentified error occurred. 2-30
0F00
The back cover sensor detected
that the cover was open in
duplex printing mode.
2-29
2D00 An unidentified error occurred. 2-30
1000 An unidentified error occurred. 2-29 2E00 An unidentified error occurred. 2-30
1100 An unidentified error occurred. 2-29 2F00 An unidentified error occurred. 2-30
1200 An unidentified error occurred. 2-29 3000 An unidentified error occurred. 2-30
1600 An unidentified error occurred. 2-29 3100 An unidentified error occurred. 2-30
1700 An unidentified error occurred. 2-29 3200 An unidentified error occurred. 2-30
1800 An unidentified error occurred. 2-29 3300 An unidentified error occurred. 2-30
1900 An unidentified error occurred. 2-29 3400 An unidentified error occurred. 2-30
1A00 An unidentified error occurred. 2-29 3500 An unidentified error occurred. 2-30
1B00 An unidentified error occurred. 2-29 3600
An error occurred in the high-
voltage power supply PCB.
2-30
1C00 An unidentified error occurred. 2-29 3700 An unidentified error occurred. 2-30
1D00 An unidentified error occurred. 2-29 3800 An unidentified error occurred. 2-30
1E00
The number of rotations of the
drum unit is reaching the life limit.
2-30 3900 An unidentified error occurred. 2-30
1F00 An unidentified error occurred. 2-30 3A00 An unidentified error occurred. 2-30
2000 An unidentified error occurred. 2-30 3B00
An error occurred during access
to the DRAM in the main PCB.
2-31
2100 An unidentified error occurred. 2-30 3C00 An unidentified error occurred. 2-31
2200 An unidentified error occurred. 2-30 3D00 An unidentified error occurred. 2-31
2300 An unidentified error occurred. 2-30 3E00 An unidentified error occurred. 2-31
2400 An unidentified error occurred. 2-30 3F00 An unidentified error occurred. 2-31
2500 An unidentified error occurred. 2-30 4000 An unidentified error occurred. 2-31
2600 An unidentified error occurred. 2-30 4200 An unidentified error occurred. 2-31
2700 An unidentified error occurred. 2-30 4300 An unidentified error occurred. 2-31
2800 An unidentified error occurred. 2-30 4400
The toner sensor detected that
the toner cartridge was not set.
2-31

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
