Brother HL-5450DN Service Manual

5-36
Confidential
1.4.2 Print font list
This function is to print the font list.
1.4.3 Change USB No. return value
When the operating system (OS) installed on the computer is Windows Vista
®
and the
machine is connected to this computer using USB2.0FULL, the OS may not be able to obtain
the USB device serial number depending on the computer and USB device. If the serial
number cannot be obtained, the number of devices increases each time the device is
connected to the computer. This problem can be avoided by fixing the USB No. return value to
"0". The setting applied is reversed each time this mode is entered.
(The same function as that described in "1.3.11 Not-disclosed-to-users functions (function
code: 45) / Change USB No. return value" in this chapter)
The setting currently applied can be determined by pressing the [Go] button three times and
checking the LED status after several seconds.
1.4.4 HEX Dump mode
In this mode, the machine prints the print data sent from the computer as HEX (hexadecimal)
data without performing emulation. This mode is used to analyze any defects in the print data
that is sent.
1.4.5 Network Reset / Factory Reset / Settings Reset
Entering each of these modes resets the items summarized in the table below.
*1
Resets only "WLAN enable".
LED display Return value setting
Toner LED lights for one
second.
Returns the serial number of the machine. (Default) →
Returns "0".
Drum LED lights for one
second.
Returns "0". → Returns the serial number of the machine.
Data item Network Reset Factory Reset Settings Reset
Counter information
Error log
Worker switches
User switches *1 99
Function setting 9
Macro 9
Font 9
MAC address
LAN setting 99
Emulation setting 99

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
