Brother HL-5450DN Service Manual

2-8
Confidential
2.4 Block Diagram
Fig. 2-3
Back cover
sensor
Main motor
LT
connector
MP-PE sensor PCB
Wireless LAN
USB
function
Panel PCB
(LED)
Panel PCB
(LCD)
LVPS PCB
Toner LED
PCB
Laser unit
Relay front
PCB
HVPS PCB
Main PCB
DIMM
Duplex
solenoid
Toner sensor PCB
Eject sensor
PCB
Backlight
PCB
T1 paper feed sensor PCB
Registration front/rear sensor PCB
Front cover sensor
LCD
T2 relay PCB
Center thermistor
Side thermistor
Halogen-heater
Power switch
Fuser unit
(Wireless LAN model only)
Toner sensor
New toner
sensor
Toner sensor
Develop clutch
MP solenoid
T1 clutch
Registration clutch
Main fan
T2 paper feed sensor PCB
T2 clutch

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
