Brother HL-5450DN Service Manual

5-20
Confidential
1.3.12 Continuous print test (function code: 67)
<Function>
This function is to conduct paper feed and eject tests while printing patterns.
<Operation Procedure>
(1) Press the [ ] or [ ] button in the initial state of maintenance mode to display
"Maintenance 67" on the LCD.
(2) Press the [OK] button. "SELECT: K 100%" is displayed on the LCD.
(3) Refer to the table below (print pattern), and press the [ ] or [ ] button to select the
print pattern.
(4) Press the [OK] button. "SELECT: A4" is displayed on the LCD.
(5) Refer to the table below (paper size), and press the [ ] or [ ] button to select the
paper size.
(6) Press the [OK] button. "SELECT: TRAY1" is displayed on the LCD.
(7) Refer to the table below (print type), and press the [ ] or [ ] button to select the print
type.
(8) Press the [OK] button. "PAPER FEED TEST" is displayed on the LCD, and printing test
pattern starts using the selected conditions.
(9) When the [Cancel] button is pressed, test pattern printing is stopped, and the machine
returns to the initial state of maintenance mode.
Print pattern
Paper size
Print type
LCD Description
SELECT: K 100% 100% solid printing (continuous printing)
SELECT: K 1% 1% intermittent pattern printing (500-page printing)
SELECT: K 5% 5% intermittent pattern printing (500-page printing)
SELECT: Lattice Lattice printing (continuous printing)
LCD Description
SELECT: A4 A4
SELECT: LETTER Letter
LCD Description
SELECT: TRAY1 Single-side printing from paper tray 1
SELECT: TRAY2 Single-side printing from paper tray 2
SELECT: MP Single-side printing from MP tray
SELECT: TRAY1 DX Duplex printing from paper tray 1
SELECT: TRAY2 DX Duplex printing from paper tray 2
SELECT: MP DX Duplex printing from MP tray
Note:
• Duplex printing only supports 5% intermittent pattern printing. Single-side printing
applies to other patterns even when duplex printing is specified.

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
