1. SPECIFICATIONS LIST
1.1 General
Specifications are subject to change without notice.
Model
HL-5440D HL-5450DN HL-5450DNT HL-5470DW HL-5470DWT
Print method Electrophotographic Laser Printer
Resolution
1200 x 1200 dpi, HQ1200 (2400 x 600 dpi) quality, 600 x 600 dpi
Print speed One-sided Up to 38/40 ppm (A4/Letter size)
Two-sided 18/18 sides per minute (9/9 sheets per minute) (A4/Letter size)
Warm-up
time
From Sleep
mode
Less than 1 second at 73.4F / 50% (23°C / 50%)
From Power
OFF → ON
Less than 25 seconds at 73.4F / 50% (23°C / 50%)
First print
time
From Ready
mode
Less than 8.5 seconds at 73.4F (23°C) / 115V or 230V
From Sleep
mode
Less than 10 seconds at 73.4F (23°C) / 115V or 230V
CPU StarSapphire 400 MHz
Memory Standard 64 MB 128 MB
Option
N/A Up to 256 MB (DDR2 16 bit, 144 pin)
Interface
Parallel
(IEEE1284)
Hi-Speed
USB 2.0
Hi-Speed USB 2.0
10Base-T/100Base-TX
Hi-Speed USB 2.0
10Base-T/100Base-TX
IEEE 802.11b/g/n
(Infrastructure Mode /
Adhoc Mode)
Power
consumption
Peak Average: Approximately 1200 W
Printing Average: Approximately 716 W (for U.S.A.), 665 W (for Europe,
Asia, China, Oceania)
Printing
(Quiet Mode)
Average: Approximately 348 W (for U.S.A.), 332 W (for Europe,
Asia, China, Oceania)
Ready Average: Approximately 5.0 W (for U.S.A.), 4.7 W (for Europe,
Asia, China, Oceania)
Sleep, Wireless
LAN: ON
N/A Average: Approximately
2.9 W (for U.S.A.), 2.8 W
(for Europe, Asia, Oceania)
Deep Sleep Average:
Approximately
0.7 W
Average: Approximately
0.6 W
Average: Approximately
0.6 W (for U.S.A.), 0.7 W
(for Europe, Asia, Oceania)
Auto Power
Down Mode
Approximately
0.4 W (only
for Europe
and GULF)
Approximately 0.41 W (only
for Europe and GULF)
Approximately 0.5 W (only
for Europe and GULF)

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
