Brother HL-5450DN Service Manual

5-32
Confidential
1.3.19 Display machine log information (function code: 80)
<Function>
This function is to display the log information on the LCD.
<Operation Procedure>
(1) Press the [ ] or [ ] button in the initial state of maintenance mode to display
"Maintenance 80" on the LCD.
(2) Press the [OK] button. "USB:********" is displayed on the LCD.
(The machine serial number is displayed for ********.)
(3) Each press of the [Go] button changes the display item.
(4) When the [Cancel] button is pressed, the machine returns to the initial state of
maintenance mode.
Display information
LCD Description
USB:000G8J000166 Serial number
MAC:008077112233 MAC address
PCB:911309123456 Main PCB serial number
KTN_ERM:87% *
4
Estimated remaining toner amount detected by toner sensor
KTN_RRM:67% *
4
Estimated remaining toner amount based on the rotations of
developer roller
DRUM_PG:00000000 Printed pages for drum
PFMP_PG:00000000 Pages fed from MP paper feeding kit
PFK1_PG:00000000 Pages fed from paper feeding kit 1
PFK2_PG:00000000 Pages fed from paper feeding kit 2
FUSR_PG:00000000 Printed pages for fuser unit
LASR_PG:00000000 Printed pages for laser unit
TTL_PG:00000000 Total printed pages
KCVRGUSI:4.32% Average coverage by the toner cartridge which is currently used
KCVRGACC:3.47% Accumulated average coverage
DRUM:00000000 Rotations of the drum
KTN_RND: 00000000 Rotations of the developer roller
MP_PG:00000000 Pages printed from MP tray
TR1_PG:00000000 Pages printed from paper tray 1
DX_PG:00000000 Duplex printed pages
TR2_PG:00000000 Pages printed from paper tray 2
A4+LTR:00000000 Printed pages of A4 size and Letter size paper
LG+FOL:00000000 Printed pages of Legal size and Folio size paper
B5+EXE:00000000 Printed pages of B5 size and EXE size paper
ENVLOP:00000000 Printed envelopes
A5 :00000000 Printed pages of A5 size paper
OTHER :00000000 Printed pages of other types of paper
PLTNRE:00000000 Total printed pages of plain, thin, and recycled paper
TKTRBD:00000000 Total printed pages of thick, ultra-thick, and bond paper
ENVTYP:00000000 Total printed pages of envelope, thick envelope, and thin
envelope

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
