Brother HL-5450DN Service Manual

5-33
Confidential
*1
When the [OK] button is pressed while the machine error is displayed, the LCD changes to
"PGCNT:*******". The total printed pages at the error occurrence is displayed for "*******".
*2
When the [OK] button is pressed while the number of times the part has been replaced is
displayed, the LCD changes to "DATE_XX:*******". The abbreviation of each part is
displayed for "XX" and the latest replacement date is displayed for "*******".
*3
When the [OK] button is pressed while the engine error is displayed, the LCD changes to
"TM:***** BT: ***". The minutes that has passed from the previous error is displayed for
"TM", and the number of times that the power is turned ON is displayed for "BT".
*4
When the [OK] button is pressed while this item is displayed, the LCD changes to
"PGCNT:*******". The total printed pages at the error occurrence is displayed for "*******".
LABEL:00000000 Printed labels
HAGAKI:00000000 Printed post cards
TTL_JAM:00000000 Total paper jams that have occurred
MP_JAM:00000000 Paper jams that have occurred in the MP tray
TR1_JAM:00000000 Paper jams that have occurred in paper tray 1
IN_JAM:00000000 Paper jams that have occurred in the machine
RE_JAM:00000000 Paper jams that have occurred at the ejecting section or back
cover
DX_JAM:00000000 Paper jams that have occurred when duplex printing
TR2_JAM:00000000 Paper jams that have occurred in paper tray 2
POWER:00000375 Total power distribution time
PWRCNT:00000000 The number of times that the power is turned ON
MACERR_01:0000 *
1
Machine error log (last ten errors)
KTN_CH:0000 *
2
The number of times that the toner cartridge has been replaced
DRUM_CH:0000 *
2
The number of times that the drum unit has been replaced
FUSR_CH:0000 *
2
The number of times that the fuser unit has been replaced
LASER_CH:0000 *
2
The number of times that the laser unit has been replaced
PFMP_CH:0000 *
2
The number of times that the MP paper feeding kit has been
replaced
PFK1_CH:0000 *
2
The number of times that paper feeding kit 1 has been replaced
PFK2_CH:0000 *
2
The number of times that paper feeding kit 2 has been replaced
KTN_PG1:000000 Pages printed with the current toner cartridge
KTN_PG2:000000 Pages printed with the previous toner cartridge
KDEV_BIAS:400V Developing bias voltage value
ENGERR01:000000 *
3
Engine error log (past ten errors)
HODN_ER:0000 The number of discharge errors
FUSR_ER:0000 The number of fuser unit errors
MTLK_ER:0000 The number of laser unit polygon motor errors
DEVSTATUS__01:00 *
4
Log for design analysis
LCD Description

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
