5-24
Confidential
1.3.14 Print frame pattern (duplex printing) (function code: 70)
<Function>
This function is to print the frame pattern on both sides of the paper and check for printing
flaws.
<Operation Procedure>
Be sure to set the Letter size paper for test pattern printing before commencing the following
procedure.
(1) Press the [ ] or [ ] button in the initial state of maintenance mode to display
"Maintenance 70" on the LCD.
(2) Press the [OK] button. "PRINTING" is displayed on the LCD, and the frame pattern is
printed on both sides of the paper.
(3) When printing is completed, "WAKU DX" is displayed on the LCD.
If printing fails, printing is stopped with displaying any of the errors shown in the table
below. To retry printing, refer to the "Remedy" in the table below to eliminate the error
cause, and press the [Go] button.
"WAKU DX" is displayed on the LCD. Press the [OK] button.
"PRINTING" is displayed on the LCD, and the frame pattern is printed on both sides of
the paper.
(4) To print the frame pattern again, press the [OK] button.
(5) When the [Cancel] button is pressed, the machine returns to the initial state of
maintenance mode.
Error display
LCD Remedy
Replace Toner Replace the toner cartridge.
Cover is Open Close the front cover.
No Paper Set paper and close the paper tray.
Jam Tray1 Remove the jammed paper and close the paper tray.
Jam Rear Remove the jammed paper and close all covers.
To Next Page
