3.2 Error Messages
The error messages displayed on the LCD of the machine and their description are shown in
the table below.
Error Message Description
Error
codes
Refer
to:
Access Denied Failed to authenticate the print limit ID when
PC-print was executed.
--- 2-73
Cartridge Error The new toner sensor could not detect the new
toner cartridge correctly.
C000 2-49
Connection Error Multiple access points were found as a result
of the access point search.
--- 2-74
Connection Fail Connection failed although the access point
was found as a result of the access point
search.
--- 2-74
Cooling Down The side thermistor of the fuser unit detected a
temperature higher than the specified value.
7500 2-38
Cover is Open The front cover sensor detected that the front
cover was open.
A100 2-49
The eject sensor detected that the fuser cover
was open.
5600 2-33
When the power switch was turned ON, the
eject sensor detected paper pass or detected
that the fuser cover was open.
8D00 2-44
DIMM Error Detected that DIMM was faulty or was
mounted incorrectly.
C900 2-50
Drum End Soon The number of rotations of the drum unit is
reaching the life limit.
1E00 2-30
Drum Error Detected discharge that may be attributable to
dirty corona wire on the drum unit.
7D00 2-40
Drum Stop Detected discharge when the number of
rotations of the drum has exceeded twice the
life limit.
8300 2-40
Duplex Disabled The back cover sensor detected that the cover
was open in duplex printing mode.
0F00 2-29
Fuser Error An error occurred in the fuser unit when the
power switch was turned ON or sleep mode
was released.
5800
5900
6A00
6B00
6C00
6D00
6E00
6F00
7600
7800
DD00
DE00
E200
2-35
2-35
2-37
2-37
2-37
2-37
2-37
2-37
2-39
2-39
2-51
2-52
2-53
Ignore Data Detected undecodable data during printing.
Received undecodable PS data.
--- 2-73
Jam Duplex The registration front sensor does not detect
paper pass within the specified time after the
first side was printed in duplex printing mode.
5700 2-34
Jam Inside The eject sensor does not detect paper pass
after the registration rear sensor detected the
end of paper pass.
8800 2-42

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
