Brother HL-5450DN Service Manual

2-11
Confidential
Error
codes
Problem
Refer
to:
Error
codes
Problem
Refer
to:
4500 An unidentified error occurred. 2-31 5B00 An unidentified error occurred. 2-35
4600 An unidentified error occurred. 2-31 5C00 An unidentified error occurred. 2-35
4700 An unidentified error occurred. 2-31 5D00 An unidentified error occurred. 2-35
4800 An unidentified error occurred. 2-31 5E00 An unidentified error occurred. 2-35
4900 An unidentified error occurred. 2-31 5F00 An unidentified error occurred. 2-35
4A00 An unidentified error occurred. 2-31 6000 An unidentified error occurred. 2-35
4B00 An unidentified error occurred. 2-31 6100 An unidentified error occurred. 2-35
4C00 An unidentified error occurred. 2-31 6200 An unidentified error occurred. 2-35
4D00 An unidentified error occurred. 2-31 6300
The toner sensor detected no
toner remaining or the number of
rotations of the developer roller
has reached the upper limit.
2-36
4E00 An unidentified error occurred. 2-31 6400 An unidentified error occurred. 2-36
4F00 An unidentified error occurred. 2-31 6500 An unidentified error occurred. 2-36
5000
The number of rotations of the
drum unit has reached the life
limit. (Printing does not stop.)
2-32
6600 An unidentified error occurred. 2-36
5100
Printable pages set for the MP
paper feeding kit have reached
the limit. (Printing does not stop.)
2-32 6700
The toner sensor detected that
the toner remaining has fallen
below the specified level or the
developer roller counter has
exceeded the specified value.
2-36
5200
Printable pages set for paper
feeding kit 1 have reached the
limit. (Printing does not stop.)
2-32
6800 An unidentified error occurred. 2-36
5300
Printable pages set for paper
feeding kit 2 have reached the
limit. (Printing does not stop.)
2-32
6900 An unidentified error occurred. 2-36
5400
Printable pages set for the fuser
unit have reached the limit.
(Printing does not stop.)
2-32 6A00
The center thermistor of the fuser unit
has not reached the specified
temperature within the specified time.
2-37
5500
Printable pages set for the laser
unit have reached the limit.
(Printing does not stop.)
2-33 6B00
The center thermistor of the fuser unit
has not reached the specified
temperature within the specified time.
2-37
5600
The eject sensor detected that
the fuser cover was open.
2-33 6C00
The center thermistor of the
fuser unit detected a
temperature higher than the
specified value.
2-37
5700
The registration front sensor
does not detect paper pass
within the specified time after the
first side was printed in duplex
printing mode.
2-34 6D00
After the heat unit was heated
normally, the center thermistor of
the fuser unit detected a
temperature lower than the
specified value.
2-37
5800
Any of error codes 6A00 to 6F00,
7600, 7800, DD00,DE00, or E200
(fuser unit error) occurred when
the power switch was turned ON
or sleep mode was released.
2-35 6E00
The center thermistor of the
fuser unit detected that the heat
unit was not heated.
2-37
5900
Rechecking the error after the power
switch was turned OFF and then ON
again because an error was detected
by the center thermistor of the fuser
unit. (This message is displayed for
approximately 15 minutes when the
machine is restarted after error code
5800 has occurred.)
2-35 6F00
The center thermistor or the side
thermistor of the fuser unit
detected a temperature error.
2-37
5A00 An unidentified error occurred. 2-35 7000 An unidentified error occurred. 2-38

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
