Brother HL-5450DN Service Manual

5-30
Confidential
Display information
*1
KO : T1 paper feed sensor OFF time / T1 paper feed sensor ON time
MN : Registration front sensor OFF time / Registration front sensor ON time
RS : Registration rear sensor OFF time / Registration rear sensor ON time
EJ : Eject sensor OFF time / Eject sensor ON time
1 Model name 21 Remaining life of laser unit
2 Serial number 22 Total printed pages
3 Model code 23 Accumulated average coverage
4
Check sum for WSW, PSW, USW, and
FSW
24
Average coverage by the toner cartridge
which is currently used
5 Main firmware version 25 Drum page count
6 Sub firmware version 26 Rotations of the drum
7 Boot firmware version 27 Rotations of the developer roller
8 Engine firmware version 28 Total printed pages per tray
9 ROM size 29 Total printed pages per paper size
10 ROM check sum 30 Total printed pages per paper type
11
USB ID code
31
Paper jams that have occurred in each
section in the machine
12
Information such as main PCB, wireless
LAN, and One Push Demo function
32
Total power distribution time
13
The number of main PCB inspections,
high-voltage inspections, discharge
errors, fuser unit errors, and polygon
motor errors
33
The number of times that the power is
turned ON
14 Not necessary for maintenance 34 Machine error log
15
Not necessary for maintenance
35
The number of times that consumables
have been replaced
16
Estimated remaining toner amount
36
Pages printed with the current toner
cartridge and previous toner cartridge
17 Remaining life of drum unit 37 Developing bias voltage value
18 Remaining life of MP paper feeding kit 38 Engine sensor operation status
*1
19 Remaining life of paper feeding kit 1 39 Engine error log
20 Remaining life of fuser unit

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
