Brother HL-5450DN Service Manual

2-46
Confidential
 Error code 9400
When printing from paper tray 1, the T1 paper feed sensor detected that there was no paper
set in paper tray 1.
 Error code 9500
When printing from paper tray 2, the T2 paper feed sensor detected that there was no paper
set in paper tray 2.
No Paper
<User Check>
• Set the paper in paper tray 1.
Step Cause Remedy
1
Connection failure of the T1
paper feed sensor harness
Check the connection of the T1 paper feed
sensor PCB harness, and reconnect it if
necessary.
2
T1 paper feed actuator caught
in some sections of the machine
Reattach the T1 paper feed actuator.
3
T1 paper feed actuator is bent
or has failed
Replace the T1 paper feed actuator.
4
T1 paper feed sensor failure Refer to "1.3.8 Check sensor operation
(function code: 32)" in Chapter 5 to check the
sensor operation. If the sensor operation is
faulty, replace the T1 paper feed sensor PCB
ASSY.
5
High-voltage power supply PCB
failure
Replace the high-voltage power supply PCB
ASSY.
6 Main PCB failure Replace the main PCB ASSY.
No Paper
<User Check>
• Set the paper in paper tray 2.
Step Cause Remedy
1
Connection failure of the T2
paper feed sensor harness
Check the connection of the T2 paper feed
sensor harness, and reconnect it if necessary.
2
T2 paper feed actuator caught
in some sections of the machine
Reattach the T2 paper feed actuator.
3 T2 paper feed actuator failure Replace the T2 paper feed actuator.
4
T2 paper feed sensor failure Refer to "1.3.8 Check sensor operation
(function code: 32)" in Chapter 5 to check the
sensor operation. If the sensor operation is
faulty, replace the T2 paper feed sensor PCB
ASSY.
5 T2 relay PCB failure Replace the T2 relay PCB ASSY.
6 LT connector failure Replace the LT connector
7 Main PCB failure Replace the main PCB ASSY.

Brother HL-5450DN Specifications

General

Color	No
N-up printing	2, 4, 9, 16, 25
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	8.5 s
Print speed (black, normal quality, A4/US Letter)	38 ppm
Duplex print speed (black, normal quality, A4/US Letter)	9 ppm
Maximum duty cycle	- pages per month
Recommended duty cycle	1000 - 3500 pages per month
Number of print cartridges	1
Memory type	DDR2
Processor family	Star Sapphire
Maximum internal memory	320 MB
Sound power level (standby)	34 dB
Sound pressure level (printing)	59 dB
Sound pressure level (quiet mode)	54 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	800 sheets
Total number of input trays	2
Multi-Purpose tray input capacity	50 sheets
Custom media width	76.2 - 215.9 mm
Maximum print size	216 x 356 mm
Custom media length	127 - 355.6 mm
Paper tray media types	Plain paper, Recycled paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Letter
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Multi-purpose tray media types	Bond paper, Envelopes, Heavyweight paper, Labels, Plain paper, Recycled paper
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Standard interfaces	Ethernet, USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.41 W
Power consumption (standby)	4.7 W
Power consumption (printing)	665 W
Power consumption (PowerSave)	0.6 W
Package weight	11.900 g
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Dimensions (WxDxH)	371 x 384 x 245 mm
