Brother MFC-9140CDN - Exit Roller Bushing;Eject Roller ASSY

3-147
Confidential
8.63 Exit Roller Bushing/Eject Roller ASSY
(1) Remove the Pin to remove the Exit roller bushing from the left side of the Paper eject ASSY .
Fig. 3-212
(2) Remove the other Exit roller bushing in the same way.
(3) Remove the Eject roller ASSY from the Paper eject ASSY.
Fig. 3-213
Pin
Paper eject ASSY
Exit roller bushing
Exit roller bushing
1b
1a
Paper eject ASSY
Eject roller ASSY
3a
3b
