1.3 List of Maintenance-mode Functions
Function
code
Function Refer to:
01 EEPROM parameter initialization 1.4.1 (5-5)
05 Printout of scanning compensation data 1.4.2 (5-6)
06 Placement of CIS unit in position for transportation 1.4.3 (5-11)
08 ADF performance test 1.4.4 (5-11)
09 Monochrome image quality test pattern 1.4.5 (5-12)
10 Worker switch (WSW) setting 1.4.6 [1] (5-13)
11 Printout of worker switch (WSW) data 1.4.6 [2] (5-16)
12 Operation check of LCD 1.4.7 (5-17)
13 Operational check of control panel key 1.4.8 (5-18)
25 Software version check 1.4.9 (5-19)
32 Operational check of sensors 1.4.10 (5-20)
33 LAN connection status display 1.4.11 (5-22)
41 Backup of machine information 1.4.12 (5-23)
43 PC print function setting 1.4.13 (5-25)
45
Changing return value of USB No./Switching Dither Pattern/
Switching of ON/OFF of DirectPrint Color mode-Improve
Gray Color/Switching of timing to execute Auto Registration/
Adjusting left-end print start position on second side in
duplex printing (2-sided printing model only)
1.4.14 (5-29)
52 Set country/language 1.4.15 (5-32)
53 Transfer of received fax data and log information 1.4.16 (5-33)
54 Fine adjustment of scan positions 1.4.17 (5-35)
55
Acquisition of white level data and setting of CIS scanning area
1.4.18 (5-36)
57 Motor reset 1.4.19 (5-37)
61 Adjustment of touch panel 1.4.20 (5-38)
66 Adjustment of color registration
(Adjustment of inter-color position alignment)
1.4.21 (5-39)
67 Print test 1.4.22 (5-42)
68 LED test pattern print 1.4.23 (5-45)
69 Frame pattern print (One-sided) 1.4.24 (5-47)
70 Frame pattern print (Two-sided) 1.4.25 (5-48)
71 Color test pattern 1.4.26 (5-49)
72 Sensitivity adjustment of density sensor 1.4.27 (5-52)
73 Continuous adjustments of density and registration sensor 1.4.28 (5-53)
74
Setting by country 1.4.29 (5-54)
77
Printout of maintenance information 1.4.30 (5-56)
78
Operational check of fans 1.4.31 (5-59)
