Brother MFC-9140CDN Service Manual

5-39
Confidential
1.4.21 Adjustment of color registration
(Adjustment of inter-color position alignment) (Function code 66)
<Function>
This function allows service personnel to forcibly activate the adjustment of color registration
(adjustment of inter-color position alignment) function which is usually executed automatically
under a specified condition. If adjustment of inter-color position alignment (auto) fails because
toner reaches its life, etc, you can adjust inter-color position alignment manually.
The end users are allowed to perform "Adjustment of inter-color position alignment
without registration sensor calibration (auto) " , " Printing of misregistration correction chart " and
"Adjustment of inter-color position alignment (manual)" only.
This function has the following functions.
■ Adjustment of inter-color position alignment without registration sensor
calibration (auto)
<Operating procedure>
(1) Press the 6 key twice in the initial state of the maintenance mode.
"REGISTRATION" is displayed on the LCD.
(2) Press the SET key. "PLS WAIT 66-1" is displayed on the LCD, and adjustment of
inter-color position alignment is automatically done.
(3) When this operation is completed without an error, "COMPLETED" is displayed on the
LCD.
(4) Press the Cancel key to return the machine to the initial state of the maintenance mode.
Note:
If an error occurs after executing Maintenance mode 66, upgrade the firmware to the latest
one. (Refer to "1.1 Installing the Firmware " in Chapter 4.) After upgrading the firmware,
execute Maintenance mode 66 again.
Function Description LCD
Adjustment of inter-color
position alignment
without registration
sensor calibration (auto)
Automatically correct misregistration
between colors that occurs as the number
of printed pages increases and time
passes.
REGISTRATION
Printing of
misregistration
correction chart
Print the chart that you check for an input
value when manually correcting
misregistration between colors.
PRINT CHART
Input of sensor offset
value
Unavailable for maintenance work. OFFSET
ADJUST
Adjustment of inter-color
position alignment
( manual )
Using the chart, manually correct
misregistration between colors that occurs
as the number of printed pages increases
and time passes. This is performed when
automatic adjustment fails.
SET
REGISTRATION
Adjustment of inter-color
position alignment
including registration
sensor calibration (auto)
After the sensitivity adjustment of
registration sensor, correct misregistration
between colors that occurs as the number
of printed pages increases and time passes.
ADD
REGISTRATION
Memo:
If the Adjustment of inter-color position alignment without registration sensor calibration
(auto) fails while being in process, "ERROR 66-1" is displayed on the LCD.
Refer to the error message list on P5-41 for the troubleshooting.

Brother MFC-9140CDN Specifications

General

Print technology	LED
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Duplex printing mode	Auto
Warm-up time (from sleep mode)	24 s
Time to first page (black, normal)	16 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	3.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Time to first copy (black, normal)	19 s
Time to first copy (color, normal)	22 s
Copy speed (black, normal quality, A4)	22 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR
Scan drivers	ICA, ISIS, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Film scanning	No
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Image formats supported	JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Fax speed dialing (max numbers)	200
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	300 - 1500 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	116 - 355.6 mm
Paper tray media types	Glossy paper, Heavy paper, Labels, Plain paper, Pre-Printed, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	3.7 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Sound power level (standby)	33 dB
Sound pressure level (printing)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.05 W
Power consumption (standby)	70 W
Power consumption (PowerSave)	7.5 W
Power consumption (average operating)	380 W
Package depth	534 mm
Package width	602 mm
Package height	565 mm
Package weight	27900 g
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	483 mm
Width	410 mm
