Brother MFC-9140CDN Service Manual

5-33
Confidential
1.4.16 Transfer of received fax data and log information (Function code 53)
<Function>
This function allows you to transfer received FAX data to another machine when the machine
cannot print the received data due to the printing mechanism failure. Activity reports,
communication lists, and machine log information can be also transferred.
<Operating procedure>
(1) Press the 5 and 3 keys in this order in the initial state of the maintenance mode.
"FAX TRANSFER" is displayed on the LCD.
- To check the number of received files, press the 1 key.
"1.NO. OF JOBS" is displayed on the LCD.
Press the SET key, and the number of received files appears, just as "NO. OF. JOBS: 10".
- To transfer the activity report only, press the 2 key.
"2.ACTIVITY" is displayed on the LCD.
- To transfer received files (together with the activity report), press the 3 key.
"3.DOCUMENTS" is displayed on the LCD.
Note that if there is no received file, the "NODOCUMENTS" appears on the LCD.
- To transfer the communication list for the latest communication, press the 4 key.
"4.COM.LIST (NEW)" is displayed on the LCD.
- To transfer the communication list for last three errors, press the 5 key.
"5.COM.LIST (ERR3)" is displayed on the LCD.
-
To transfer the maintenance information (the list in Function code 77), press the 6 key.
"6.MNT77 LIST" is displayed on the LCD.
(2) With the "2.ACTIVITY," "3.DOCUMENTS," "4.COM.LIST (NEW)," "5.COM.LIST (ERR3)"
or "6.MNT77 LIST" being displayed, press the SET key.
"ENTER NO. & SET" is displayed on the LCD.
(3) Enter the telephone number of the receiver machine and press the SET key again.
(4) The machine displays the "ACCEPTED" for approximately two seconds and starts dialing
to transfer data.
Note:
- Up to 99 files can be transferred simultaneously. When you transfer 100 files or
more, perform the following procedure multiple times.
- If there are both color and monochrome data the monochrome data will be
transferred first. If the receiver machine does not support the color function, the
sender machine cannot transfer color data, resulting in an error.
Note:
- Be sure to type the telephone number with the numerical keys. No one-touch dialing
is allowed in this procedure.
- No station ID will be attached. A cover page and end page as shown on the next
page will be automatically attached, instead.

Brother MFC-9140CDN Specifications

General

Print technology	LED
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Duplex printing mode	Auto
Warm-up time (from sleep mode)	24 s
Time to first page (black, normal)	16 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	3.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Time to first copy (black, normal)	19 s
Time to first copy (color, normal)	22 s
Copy speed (black, normal quality, A4)	22 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR
Scan drivers	ICA, ISIS, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Film scanning	No
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Image formats supported	JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Fax speed dialing (max numbers)	200
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	300 - 1500 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	116 - 355.6 mm
Paper tray media types	Glossy paper, Heavy paper, Labels, Plain paper, Pre-Printed, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	3.7 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Sound power level (standby)	33 dB
Sound pressure level (printing)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.05 W
Power consumption (standby)	70 W
Power consumption (PowerSave)	7.5 W
Power consumption (average operating)	380 W
Package depth	534 mm
Package width	602 mm
Package height	565 mm
Package weight	27900 g
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	483 mm
Width	410 mm
