Brother MFC-9140CDN Service Manual

5-53
Confidential
1.4.28 Continuous adjustments of density and registration sensor
(Function code 73)
<Function>
This function allows you to perform the following functions consecutively:
Sensitivity adjustment of density sensor (Function code 72), Developing bias voltage
correction (Function code 83), and
Adjustment of color registration (Adjustment of inter-color
position alignment) including registration
sensor calibration (Function code 66).
<Operating procedure>
(1) Press the 7 and 3 keys in this order in the initial state of the maintenance mode.
"DDRPT2" is displayed on the LCD.
(2) Press the or key to display "DDR" on the LCD.
(3) Press the SET key. "PLS WAIT 72" is displayed on the LCD and each adjustment is
performed in the following order.
1) Sensitivity adjustment of density sensor (Function code 72)
LCD: PLS WAIT 72
2) Developing bias voltage correction (Function code 83)
LCD: PLS WAIT 83
3)
Adjustment of color registration (Adjustment of inter-color position alignment)
including registration
sensor calibration (Function code 66)
LCD: PLS WAIT 66-1
(4) When all operations are completed, "COMP" is displayed on the LCD. Pressing the
key and Stop key in this order and the machine returns to the initial state of the
maintenance mode.
Note:
- If each adjustment fails, "ERROR**" is displayed on the LCD and the adjustment is
stopped. ("**" indicates the corresponding function code.) If you press the key with
"ERROR**" displayed, the details of the error are shown.
- If the details of the error indicate one of the following, scratch or dirt on the belt unit or the
drum units may cause the error: "FAILED REGIST", "NG * L:C080 R:M105",
"NG R-L:C030", "NG PWM L120 R180", "NG PWM R-L:080", "NG CNT R100 L100",
"NG S-POSI R:080", "NG SKEW:120", "NG PWM R-P L:080", "NG XMARGIN:M191".
In this case, replace the belt unit and the drum units of all four colors with the ones that do
not have any scratch or dirt, and perform the function from step (1) again. If the function
is completed successfully, mount the removed belt unit and four drum units.

Brother MFC-9140CDN Specifications

General

Print technology	LED
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Duplex printing mode	Auto
Warm-up time (from sleep mode)	24 s
Time to first page (black, normal)	16 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	3.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Time to first copy (black, normal)	19 s
Time to first copy (color, normal)	22 s
Copy speed (black, normal quality, A4)	22 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR
Scan drivers	ICA, ISIS, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Film scanning	No
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Image formats supported	JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Fax speed dialing (max numbers)	200
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	300 - 1500 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	116 - 355.6 mm
Paper tray media types	Glossy paper, Heavy paper, Labels, Plain paper, Pre-Printed, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	3.7 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Sound power level (standby)	33 dB
Sound pressure level (printing)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.05 W
Power consumption (standby)	70 W
Power consumption (PowerSave)	7.5 W
Power consumption (average operating)	380 W
Package depth	534 mm
Package width	602 mm
Package height	565 mm
Package weight	27900 g
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	483 mm
Width	410 mm
