Brother MFC-9140CDN Service Manual

2-30
Confidential
3.3 Communications Error Code
Code 1 Code 2 Cause Refer to:
10 07 No document loaded at the time of outgoing call for
document transmission.
4.11.1
10 08 Wrong FAX number called.
4.13.1
11 01 No dial tone detected before start of dialing.
4.13.1
11 02 Busy tone detected before dialing.
4.13.1
11 03 2nd dial tone not detected.
4.13.1
11 05 No loop current detected.
4.13.1
11 06 Busy tone detected after dialing or called.
4.13.1
11 07 No response from the remote terminal in calling.
4.13.1
11 10 Tone not detected after dialing.
4.13.1
11 11 No response signal after transmission of Fax2 net
command.
4.13.1
13 12 Error signal received after transmission of Fax2 net
command.
4.13.1
16 09 No cipher registered.
4.13.1
17 01 Outgoing call with a number unable to be used in
NGN line. (Equal to or more than 33 digits, or
nonnumeric characters)
4.13.2
17 07 No response from the remote terminal in receiving.
4.13.2
1C 01 Lack of access right detected in NGN line.
(T38: 403 Forbidden)
4.13.4
1C 02 File or folder (directory) not found in NGN line.
(T38: 404 Not Found)
4.13.4
1C 03 Context-sensitive acceptance impossible in NGN line.
(T38: 488 Not Acceptable Here)
4.13.4
1C 04 SIP (Session Initiation Protocol) connection not
allowed (T38)
Outgoing call with OFF selected in USW NGN fax
setting or before acquisition of SIP information.
4.13.4
1C 05 Net internal error detected. (T38)
4.13.4
1C 06 SIP server timeout. (T38)
4.13.4
1C 08 Error other than 1C01, 1C02, 1C03, 1C04, 1C06,
1D01, 1D02, and 1D04 detected.
4.13.4
1D 01 State of being busy detected in NGN line.
(T38: 486 Busy)
4.13.4
1D 02 State of being temporarily unavailable detected in
NGN line. (T38: 480 Temporarily Unavailable)
4.13.4
1D 04
Network cable not connected (upon detecting link down)
or state of not being connected to the network. (T38)
4.13.4

Brother MFC-9140CDN Specifications

General

Print technology	LED
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Duplex printing mode	Auto
Warm-up time (from sleep mode)	24 s
Time to first page (black, normal)	16 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	3.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Time to first copy (black, normal)	19 s
Time to first copy (color, normal)	22 s
Copy speed (black, normal quality, A4)	22 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR
Scan drivers	ICA, ISIS, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Film scanning	No
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Image formats supported	JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Fax speed dialing (max numbers)	200
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	300 - 1500 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	116 - 355.6 mm
Paper tray media types	Glossy paper, Heavy paper, Labels, Plain paper, Pre-Printed, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	3.7 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Sound power level (standby)	33 dB
Sound pressure level (printing)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.05 W
Power consumption (standby)	70 W
Power consumption (PowerSave)	7.5 W
Power consumption (average operating)	380 W
Package depth	534 mm
Package width	602 mm
Package height	565 mm
Package weight	27900 g
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	483 mm
Width	410 mm
