Page #380 background imageLoading...
Page #380 background image
5-42
Confidential
1.4.22 Print test (Function code 67)
<Function>
This function allows you to conduct the pick-up and delivery test as printing patterns.
<Operating procedure>
(1) Press the 6 and 7 keys in this order in the initial state of the maintenance mode.
"SELECT: K 100%" is displayed on the LCD.
(2) Referring to the table below (Print pattern), press the or key to select the desired
print pattern.
(3) Press the SET key. "SELECT: A4" is displayed on the LCD.
(4) Referring to the table on the next page (Paper size), press the or key to select the
desired paper size.
(5) Press the SET key. "SELECT: PLAIN" is displayed on the LCD.
(6) Referring to the table on the next page (Print specifications), press the or key to
select the desired print specifications.
(7) Press the SET key. "SELECT: TRAY1 SX" is displayed on the LCD.
(8) Referring to the table on the next page (Print type), press the or key to select the
desired print type.
(9) Press the SET key. "SELECT: 1PAGE" is displayed on the LCD.
(10) Referring to the table on the next page (Number of pages to be printed), press the or
key to select the desired number of pages to be printed.
(11) Press the SET key. "SELECT: 1P/JOB" is displayed on the LCD.
(Intermittent pattern printing only)
(12) Referring to the table on the next page (Number of pages per job), press the or key
to select the desired number of pages per job.
(Intermittent pattern printing only)
(13) Press the SET key. "PAPER FEED TEST" is displayed on the LCD and the test pattern
starts to be printed under the selected items for paper feed test.
(14) If you press the Stop key, printing of test pattern is interrupted and the machine returns to
the initial state of the maintenance mode.
<Print pattern>
* Up to 500 sheets in one-sided printing and 1,000 sheets in two-sided printing in the
case of job printing.
LCD Description
SELECT: K 100% Black 100% solid print
SELECT: C 100% Cyan 100% solid print
SELECT: M 100% Magenta 100% solid print
SELECT: Y 100% Yellow 100% solid print
SELECT: W 100% White 100% solid print
SELECT: R 100% Red 100% solid print
SELECT: G 100% Green 100% solid print
SELECT: B 100% Blue 100% solid print
SELECT: KCMY1% Black/Cyan/Magenta/Yellow 1% intermittent pattern print
*
SELECT: KCMY5% Black/Cyan/Magenta/Yellow 5% intermittent pattern print
*
SELECT: Lattice Lattice print
SELECT: Total Total pattern print
