Brother MFC-9140CDN Service Manual

5-57
Confidential
1 Model name 23 Not necessary for maintenance work
(ADF sensor log 1 to 4)
2 Serial number
3 Model code 24 Not necessary for maintenance work
(ADF sensor log 5 to 8)
4 Country code
5 Switch checksum (factory use) 25 Not necessary for maintenance work
(ADF sensor log 9 to 12)
6 Main firmware version
7 Sub firmware version 26 Estimated remaining life of toner (Cyan)
8 Boot firmware version 27 Estimated remaining life of toner (Magenta)
9 Demo firmware version 28 Estimated remaining life of toner (Yellow)
10 Panel firmware version 29 Estimated remaining life of toner (Black)
11 Panel boot firmware version 30 Remaining life of drum unit (Cyan)
12 ROM CheckSum 31 Remaining life of drum unit (Magenta)
13 RTC check
*1
32 Remaining life of drum unit (Yellow)
14 RTC backup
*1
33 Remaining life of drum unit (Black)
15 Time before RTC backup
*1
34 Remaining life of PF kit 1
16 Time after RTC backup
*1
35 Remaining life of belt unit
17 USB ID code 36 Remaining life of fuser unit
18 RAM size 37 Total printed page
19 Function code 72 result/
Function code 55 result/
Wireless LAN country setting/
Wireless LAN output value/
WLAN Setup setup history/
Toner type CMYK (Current)/
Toner type CMYK (Previously used)
*2
38 Total copied pages
39 Total printed PC pages
40 Total printed list/fax pages
41 Accumulated average coverage
42 Average coverage (Current toner)
43 Average coverage (Previous used toner)
20 Main PCB inspection log/
High-voltage inspection log/
Number of electric discharge errors/
Number of fuser unit errors/
Process execution state
(Function code 1 to 64)
44 Drum page count/Rotations of the drum
45 Rotations of the developer roller
(Current toner/Previous used toner)
46 Total printed pages per paper tray/
Paper size/Paper type
21 Next Power On State/
Process execution state
(Function code 65 to 128)/
Process execution checksum
47 Total printed pages by each toner cartridge
(Current toner/Previous used toner)
48 Rotations of the developer roller used in
printing (Current toner/Previous used toner)
22
Number of color correction
(hexadecimal) that has been executed
(Auto registration/
Developing bias voltage correction/
Gamma correction/
Auto registration (user)/
Developing bias voltage correction
(user)/Gamma correction (user)/
Registration error/
Color calibration flag)
49 Total number of paper jams/Paper jams that
have occurred in each section in the machine
50 Machine error log/Total pages printed by the
time of error occurrence/Temperature and
humidity at the time of error occurrence
51 Number of times that consumables and
periodical replacement parts have been
replaced
*3
52 Total pages of scanning/
Document jams that have occurred in ADF
53 Communication error log

Brother MFC-9140CDN Specifications

General

Print technology	LED
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Duplex printing mode	Auto
Warm-up time (from sleep mode)	24 s
Time to first page (black, normal)	16 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	3.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Time to first copy (black, normal)	19 s
Time to first copy (color, normal)	22 s
Copy speed (black, normal quality, A4)	22 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR
Scan drivers	ICA, ISIS, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Film scanning	No
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Image formats supported	JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Fax speed dialing (max numbers)	200
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	300 - 1500 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	116 - 355.6 mm
Paper tray media types	Glossy paper, Heavy paper, Labels, Plain paper, Pre-Printed, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	3.7 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Sound power level (standby)	33 dB
Sound pressure level (printing)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.05 W
Power consumption (standby)	70 W
Power consumption (PowerSave)	7.5 W
Power consumption (average operating)	380 W
Package depth	534 mm
Package width	602 mm
Package height	565 mm
Package weight	27900 g
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR

Weight and Dimensions

Depth	483 mm
Width	410 mm
