Brother MFC-9140CDN Service Manual

2-26
Confidential
Jam Rear Open the Back
Cover and remove
the jammed paper,
then press [Start].
After the registration rear sensor
detected that paper has passed,
the eject sensor continues to detect
paper pass.
7100 2-58
Jam Tray Pull the paper tray
completely out of
the machine and
remove the
jammed paper
After the paper feed sensor detects
paper pass, the registration front
sensor does not detect paper
pass after a set period of time.
7300 2-59
Log Access
Error
Server Timeout,
contact your
administrator.
Timeout occurred with access
request sent to server due to
incorrect server address, network
disconnection, or inactive server.
C001 2-77
Authentication
Error, contact your
administrator.
User authentication is unavailable
due to incorrect user name,
incorrect password, or
asynchronous date and time
between the machine and server.
Otherwise, the directory name is
incorrect or you have no write
access.
C002
C003
2-77
Wrong Date&Time,
contact your
administrator.
The current time necessary for user
authentication is unavailable due to
machine clock not being set and
time not being obtained through
SNTP.
C004 2-77
Manual
Feed
Load paper
No paper is in the manual feed slot
when printing from the manual feed
slot.
8C00 2-62
No Belt Unit Open the Top
Cover, pull out all 4
Drum Units
completely and
install the Belt Unit.
The registration mark sensor
detected that no belt unit was set.
6400 2-53
No HUB
Support
-
USB device with a built-in hub was
connected.
--- 2-122
No Paper Reload paper in
Tray.
For printing by feeding paper from
the paper tray, the paper feed
sensor detected that no paper was
in the paper tray.
9302 2-65
No
Permission
Function Locked
The user does not have permission
to perform color printing when PC
print is performed.
--- 2-122
No Toner Open the Top
Cover, then install
Toner Cartridge.
As the electrical continuity of the
new toner detection terminal is
broken, the machine detected that
the toner cartridge was not
installed.
6101
6102
6103
6104
2-49
Error message
Description
Error
codes
Refer
to:
Upper line Lower line

Brother MFC-9140CDN Specifications

General

Print technology	LED
Maximum resolution	600 x 2400 DPI
Economical printing	Yes
Duplex printing mode	Auto
Warm-up time (from sleep mode)	24 s
Time to first page (black, normal)	16 s
Print speed (black, normal quality, A4/US Letter)	22 ppm
Duplex print speed (black, normal quality, A4/US Letter)	3.5 ppm
Copier resize	25 - 400 %
Maximum copy resolution	600 x 600 DPI
Maximum number of copies	99 copies
N-in-1 copy function (N=)	2, 4, 9, 16, 25
Time to first copy (black, normal)	19 s
Time to first copy (color, normal)	22 s
Copy speed (black, normal quality, A4)	22 cpm
Scan to	E-mail, E-mail Server, File, FTP, Image, OCR
Scan drivers	ICA, ISIS, TWAIN, WIA
Scanner type	Flatbed & ADF scanner
Film scanning	No
Grayscale levels	256
Input color depth	48 bit
Maximum scan area	216 x 356 mm
Output color depth	24 bit
Image formats supported	JPG, PNG, TIF
Maximum scan resolution	19200 x 19200 DPI
Document formats supported	PDF
Optical scanning resolution	1200 x 2400 DPI
Faxing	Color faxing
Fax memory	500 pages
Modem speed	33.6 Kbit/s
Fax coding methods	JBIG, MH, MMR (Fax coding method), MR
Fax transmission speed	2 sec/page
Fax speed dialing (max numbers)	200
Printing colors	Black, Cyan, Magenta, Yellow
Maximum duty cycle	- pages per month
Recommended duty cycle	300 - 1500 pages per month
Number of print cartridges	4
Page description languages	BR-Script 3, PCL 6
Paper input type	Paper tray
Total input capacity	250 sheets
Total output capacity	100 sheets
Auto document feeder (ADF) input capacity	35 sheets
Custom media width	76.2 - 215.9 mm
Custom media length	116 - 355.6 mm
Paper tray media types	Glossy paper, Heavy paper, Labels, Plain paper, Pre-Printed, Recycled paper, Thin paper
Paper tray media weight	60 - 105 g/m²
Non-ISO print media sizes	Legal
ISO A-series sizes (A0...A9)	A4, A5, A6
JIS B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
Auto Document Feeder (ADF) media weight	64 - 90 g/m²
Display	TFT
Control type	Touch
Product color	Black, White
Display diagonal	3.7 \
Market positioning	Business
Standard interfaces	Ethernet, USB 2.0
Wi-Fi	-
Cabling technology	10/100Base-T(X)
Security algorithms	HTTPS, SSL/TLS
Ethernet LAN data rates	10, 100 Mbit/s
Mobile printing technologies	Apple AirPrint, Google Cloud Print
Sound power level (standby)	33 dB
Sound pressure level (printing)	53 dB
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (off)	0.05 W
Power consumption (standby)	70 W
Power consumption (PowerSave)	7.5 W
Power consumption (average operating)	380 W
Package depth	534 mm
Package width	602 mm
Package height	565 mm
Package weight	27900 g
Mac operating systems supported	Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Server operating systems supported	Windows Server 2003, Windows Server 2003 x64, Windows Server 2008, Windows Server 2008 R2, Windows Server 2008 x64, Windows Server 2012
Sustainability certificates	Nordic Swan Ecolabel, Blue Angel, ENERGY STAR
